Five33 Typhon V7 T700 Frame Kit

The Typhon was born out of the need for a 6″ light weight race frame that is durable and can compete with the fastest pilots in the world. This is a design concept SSBelmont came up and iterated on with Mason “Hyper” Lively.

• Very light and durable:
  • Overall weight w/oTPU: 64g with 5″ arms and 69g with 6″
  • Made out of T700 carbon -38.8% higher tensile strength

• Variousarm options:
  • 5″- snappier feel. more durable
  • 6″- smoother feel. cleaner air

WHAT’S IN THE PACKAGE:

Typhon Body Kit:

Carbon:

• Qty 2 2mm Arm Lock

• Qty 1 2mm Top Plate*

• Qty 1 2mm Mid Plate

• Qty 1 2mm Bottom Plate

• Qty 5 6mm Short* arms/ Qty 5 6mm Long arms

Hardware:

• Qty 4 18mm M3 Flat Head Hex Drive Screw

• Qty 2 12mm M3 Flat Head Hex Drive Screw

• Qty 6 M3 Pressnut Preinstalled

• Qty 4 20mm M3 ButtonHead Screw (Titanium)

• Qty 4 6mm M3 Flat Head

• Qty 4 20mm M3 Aluminum Standoff (Gold Color)

• Qty 4 Nylon M3 Nut

TPU (optional):

• • Nano camera pod / SMA Mount/ turtle fin
  • Additional prints availablehereandhere

*= modified Five33 Version. File available here
